Parameter:
Pixel Pitch | P6.67 |
LED Type | SMD2727 |
Module Size | 320*320 |
Cabinet Size | 1280*960*150 |
Module Resolution | 48*48 |
Cabinet Weight | 65/45kg |
Cabinet Material | Steel/ Aluminum |
Gray Scale | 16 bit |
Contrast Ratio | 2000:1 |
View Angle(H/V) | 160°/ 140° |
Refresh Rate | >1920Hz |
Brightness | >6500nits |
IP Rating | IP65 / IP54 |
Servicing | Front / Rear |
Operating Temp/Humidity | -20ºC-50ºC / 10%-90% |
Expected Lifetime | 100,000Hrs |
Average Power Consumption | 360W/ Panel |
Features
1 Using ultra-high brightness LED lamp and high-quality accessories,light uniformity, low power consumption
2 Classic module design, superior and stability product performance.
3 High-contrast of 4000:1 as well as refresh rate of 1920 hz can achieve a good display.
4 Light weight,easy to set up and tear down.
5 High brightness adjustable according to environment changes
6 It can be single-point, single lamp maintenance, low cost.
7 A wide viewing angle of 160° ensure that the clear image from every.
8 You can set several different display areas to achieve different visual display effects.Rich display types create various display effects.




Services
* We can offer customization service for customized products and can provide onsite installation and testing service.
* We provide 2 years warranty and free repair service for our products sold.
* We also provide free training to customers' engineer.
* From raw materials to every process, we have strict production and testing process to ensure that our products under the quality inspection system standards.
* At the same time, we have an aging testing of 72 hours as well as waterproof test of outdoor led display to ensure the high quality of the product
Tips
* Payment: We accept the L/C, T/T, Western Union.
* Shipment: We will ship within 30 working days after you placed the order, but the specific delivered time will be affected by the shipping company and shipping details.
* Package: We usually pack the product in a wooden box or flight case
