3840Hz P1.9 P2.5 Indoor LED Poster Screen with 30mm Thickness USB Display
Parameters:
About our company:
BAKO VISION started the business journey from 2005 in shenzhen and now become a professional LED display manufacturer.We were witnessed by customers from more than 100 countries and never stop our step to develope oversea market.
Now our company is equipped with eighteen automatic SMT lines and three DIP lines with high speed machines of Panasonic and Samsung,some of them for OEM customers and some for standard screen or large screen.We also owns experienced R & D team and comprehensive management.All of these are the factors enable us to provide advanced quality and service for our customers.
FAQ:
1. How shall I make the payment?
We accept T/T,T/C and Western Union,30% deposite to start production and 70% balance before delivery.
2. How can I choose a proper product?
Then we need to clarify some questions firstly:
A: Where will you install this display?Outdoor or Indoor?
B: How do you plan to control it?By USB or Computer?
C: What context do you want to display?
3. How do you ensure the quality?
A: We have been in LED display manufacture for more than 10 years and own our professtional team.
B: From LED to module,to cabinet,to screen and anything like power supply and control system,we have a QC team to control at every step.
C: Everytime before delivery,there will be aging testing for several days to ensure normal working.You are also welcomed to check the products in our factory.
D: We offer 2~5 years warranty and 18/7 online engineering help.
1. Three versions for your full options
Standard version, pro version, seamless Nationstar GOBversion
2. Slim, lightweight, portable
Only 27kg, 30mm thick, no bezels
3. Smart control
By USB "plug & play", WIFI connect, send video on mobile phone
4. Digital, novel advertising
A/V solutions, retail environments, conference room...
5. Quality assure
Nationstar GOB, Aluminum material, anti-scratch and good thermal effect
6. Easy and optional installation methods
Individuals, splicing, bracket standing, vertical standing base, wall mounting, hanging...
Parameters:
| Pixel Pitch | 1.9mm | 2.5mm | 2.5mm Pro | 3.0mm |
| Pixel Configuration | SMD 1515 | SMD 2121 | SMD 2121 | SMD 2121 |
| Pixel Density | 279,936pixels/m² | 169,344pixels/m² | 157,464pixels/m² | 110,889pixels/m² |
| Module Dimention(mm) | 160 × 160 | 160 × 160 | 280 × 210 | 192 × 192 |
| Whole Set Dimention(mm) | 640 × 1920 × 35 | 640 × 1920 × 35 | 571× 1897 × 33 | 574 × 1928 × 35 |
| NO.of Modules Per Panel | 4 × 12 | 2 × 9 | 2 × 9 | 2 × 9 |
| Resolution of Module | 84 x 84 | 64× 64 | 108× 81 | 64 × 64 |
| Resolution of Whole Set | 336 × 1,010 | 256 × 768 | 216 × 729 | 192× 640 |
| Panel Material | Aluminum | |||
| Cabinet Weight | 32 kg | 32 kg | 28 kg | 32 kg |
| Gray Level | 16 bit(281 trillion colors) | |||
| Contrast Ratio | 4000 : 1 | 4000 : 1 | 4000 : 1 | 4000 : 1 |
| Average Power Consumption | 250W/Set | 200W/Set | 100 W/ Set | 200 W/ Set |
| Max Power Consumption | 750W/Set | 600W/Set | 390 W / Set | 600 W / Set |
| Driving Method | 1/32 Scan | 1/32 Scan | 1/27 Scan | 1/32 Scan |
| Brightness | >1,000 nits | >1,000 nits | >1,000/3500 nits | >1,000 nits |
| Refresh Rate | ≥2,880 Hz | ≥2,880 Hz | ≥3,840 Hz | ≥2,880 Hz |
| Viewing Angle(V/H) | 160°/ 140° | |||
| Frame Rate | 60 fps | |||
| Operating Temp/Humidity | -10ºC~60ºC / 10%~60% | |||
| Storage Temp/Humidity | -30ºC~60ºC / 10%~60% | |||
| IP Rating(Front/Rear) | IP40 | |||
| Expected Lifetime | 100,000 Hrs | |||
About our company:
BAKO VISION started the business journey from 2005 in shenzhen and now become a professional LED display manufacturer.We were witnessed by customers from more than 100 countries and never stop our step to develope oversea market.
Now our company is equipped with eighteen automatic SMT lines and three DIP lines with high speed machines of Panasonic and Samsung,some of them for OEM customers and some for standard screen or large screen.We also owns experienced R & D team and comprehensive management.All of these are the factors enable us to provide advanced quality and service for our customers.
FAQ:
1. How shall I make the payment?
We accept T/T,T/C and Western Union,30% deposite to start production and 70% balance before delivery.
2. How can I choose a proper product?
Then we need to clarify some questions firstly:
A: Where will you install this display?Outdoor or Indoor?
B: How do you plan to control it?By USB or Computer?
C: What context do you want to display?
3. How do you ensure the quality?
A: We have been in LED display manufacture for more than 10 years and own our professtional team.
B: From LED to module,to cabinet,to screen and anything like power supply and control system,we have a QC team to control at every step.
C: Everytime before delivery,there will be aging testing for several days to ensure normal working.You are also welcomed to check the products in our factory.
D: We offer 2~5 years warranty and 18/7 online engineering help.
